Chapter 1: Module Overview 1-3
Owner’s Guide 0300199-01 Rev. D
FPGA. The FPGA reads the input signals and converts them to counter and rate,
and then presents them in floating point values. The input circuitry also supports
gate inputs, allowing you to disable and control counter operation.
Cable length should be kept to a minimum. Use the lowest capacitance shielded
cable available. We recommend that you use Belden #9501 (or equivalent).
Table 1-2. Cable Specifications
Description
Belden #9501
When used?
AC/DC inputs.
Conductors
2, #24 AWG tinned
copper (7×32)
Shield
Belden foil
aluminum polyester
shield with copper
drain wire.
Jacket
Chrome PVC
Agency Approval
NEC Type CM
Temperature Rating
80 °C
