Spectrum Controls 1756-CTR8 - Errors

7-4 Chapter 7: Troubleshooting
Owner’s Guide 0300199-01 Rev. D
16#0F04 - .ConfigurationRevError
If the .ConfigurationRevNumber tag is 1 and a second owner attempts to connect
with a different configuration, this error will occur. You must adjust the second
owner’s configuration to match the first.
16#0F05 - .ConfigurationRevNumber Error
An invalid value has been entered into this tag.
Channel Specific Errors
NOTE
n = channel number (0-7)
0×010(
n
)
Preset is defined larger than rollover limit for channel (
n
).
0×0200 Input Range mismatch for channel pair 0 and 1.
0×0202
Input Range mismatch for channel pair 2 and 3.
0×0204 Input Range mismatch for channel pair 4 and 5.
0×0206 Input Range mismatch for channel pair 5 and 7.
0×030(n) Invalid operational mode for channel (n).
0×040(n) Invalid storage mode for channel (n).
0×050(n) Invalid input range for channel (n).
0×060(n) Invalid signal filter for channel (n).
0×070(n) RateSamplePeriod out of range for channel (n).
0×0800 Operational mode mismatch for channel pair 0 and 1.
0×0802 Operational mode mismatch for channel pair 2 and 3.
0×0804 Operational mode mismatch for channel pair 4 and 5.
0×0806 Operational mode mismatch for channel pair 6 and 7.
0×090(n) Preset too high for channel (n).
0×0A0(n) Count limit too high for channel (n).
0×0B0(n) RateSamplePeriod not divisible by 10 for channel (n).
NOTE
If there are multiple errors in the configuration tags only one will be
displayed at a time. Once the displayed error has been corrected, the
additional errors will be displayed upon reconnection to the module. Each
error must be resolved before a running connection will be allowed.
