Owner’s Guide 0300199-01 Rev. D
Chapter 5
Configuration, Data, and Status
Tags
Read this chapter to:
• Send configuration data to the module.
• Configure global module properties.
• Configure each input channel.
• Check each input channel’s data.
• Check module and individual channel status.
This chapter outlines the detailed settings for the 1756sc-CTR8. These settings
determine the modules input types, filter frequencies, scan rates, and associated
attributes. Detailed descriptions of these settings are available in the Tag
Definition section of this chapter.
NOTE
The following format is used to describe tags:
Tag Name Range Data Type
After changing the configuration tags in this chapter, you must then send them to
the module. To do this you may perform any of these operations:
1. Inhibit, then un-inhibit, the module via the Module Properties dialog;
Connection Tab.
2. Reset the module via the Module Properties dialog; Module Info tab.
3. Reset the module via ladder logic. See the DoReset rung in the sample ladder
project.
4. Perform a Set Attribute All or Module Reconfigure message instruction via
ladder logic. Refer to your sample program for information about the
DoSetAttrAll command.
NOTE
If an invalid configuration is sent to the module a connection error will
occur. See chapter 7 for a list of error codes.
