7
EN
Charger AC to DC Power Supply
Input Connector
5.5mm x 2.5mm Barrel
Connector (center pin
positive)
IEC-320-C5 AC input,
Standard IEC-320-C5
AC power cord included
Output Connector iC3
™
(EC3
™
compatible)
5.5mm x 2.5mm Barrel
Connector (center pin
positive)
Input Voltage 19–24V DC 110–120V AC
Max. Output Voltage 17.4V (4.35 x 4 for LiHV) 20V
Max. Output Current 5A 3A
Standard Battery Parameters
Battery Type LiPo LiFe LiHV NiMH
Nominal Voltage (per cell)
3.7V 3.3V 3.7V 1.2V
Max Charge Voltage (per cell) 4.2V 3.6V 4.35V 1.5V
Storage Voltage (per cell) 3.8V 3.3V 3.85V n/a
Allowable Fast Charge Rate ≤1C ≤4C ≤1C ≤1C
Minimum Discharge Voltage (per cell)
3.0V 2.6V 3.1V 0.9V
