Spectrum Smart S150 - Device Layout and Components

LiHV
LiPo
LiFe
NiMH
5.0A
3.0A
1.0A
0.5A
F
E
D
K
L
J
LiHV
LiPo
LiFe
NiMH
5.0A
3.0A
1.0A
0.5A
G
A
B
C
H
I
2S
3S
4S
8
EN
Layout
A Update Port
B Cooling Fan
C DC Power Input
D Battery Type
E Charge Status
F Charge Current
G Selection Button
H Battery Balance Connector
I IC3 Battery Port
J DC Power Connector
K AC to DC Power Supply
L AC Power Input Cable
