Peripheral Connection
2.1
Included Accessories: Soldering Practice Board and External 5/9V BEC
The included soldering practice board has the same pad layout as the F405 AIO.
It is recommended to scan the QR code to watch the soldering tutorial and
practice on the board before performing the actual soldering.
The external BEC can be used to power peripherals such as a
9V VTX or 5V Meteor LED strips. By default, it outputs 5V,
and by short-circuiting the two pads, it will output 9V.
Default Output: 5V
Optional output: 9V
Soldering
Practice Board
External BEC
To Next Page
