SpeedyBee F405 V3 - Connection with Motors & Power Cable

11/14
Connection with Motors & Power Cable
Note: In order to prevent the stack from being burnt out by voltage spikes
on powering up, it is strongly recommended to use the Low ESR capacitor in
the package.
Motor 4
Motor 3
Motor 2
Motor 1
XT60 Power Cable
1000uF Low ESR
Capacitor
