Cable Connection vs DJI O3 Air Unit
Cable Connection vs RunCam Link/
Caddx Vista Air Unit
Cable Connection Vs DJI Air Unit V1
7.4-26.4V
GND
RX
TX
GND
SBUS
Use 6-pin cable comes with the O3 Air Unit
Use 6-pin cable comes with the F405 V3 stack
(See the accesso No.10 in the package section)
Use 6-pin cable comes with the F405 V3 stack
(See the accesso No.10 in the package section)
