Spektrum SPM4649T User Manual

EN
3
SPM4649T Instruction Manual
Specifi cations
SPM4649T
Type Remote Serial Telemetry Receiver
Dimensions (LxWxH) 30 x 16 x 6mm
Channels 20
Weight 3g
Band 2.4GHz
Input Voltage 4-8.4V
Compatibility
All DSM2 and DSMX Aircraft Transmitters and
Module Systems. 11ms and 20 channel support
(limited to transmitter capabilities)
The SPM4649T remote serial receiver is a full range telemetry receiver
featuring DSM
®
technology and is compatible with all Spektrum™ aircraft
radios that support DSM2
®
and DSMX
®
technology.
Telemetry requires a Spektrum telemetry capable transmitters.
For more information on Spektrum Telemetry visit:
http://www.spektrumrc.com
Diversity Antennas
The SPM4649T incorporates two antennas for diversity. Each antenna includes
acoaxial portion (which can be thought of as an extension) and an exposed
31mm tip antenna. The last 31mm is the active portion of the antenna. Do not
allow the antennas to kink and never cut the antennas.
The antennas can easily be changed if damaged. Simply unsnap the damaged
antenna and replace with a new antenna (SPM4648ANT).
Y-Harness
Bind/Prog Port
Antennas
Laps/Volts/RPM port
Bind/Serial port
Power end
