EN
4
Smart Throttle
With Smart Technology the normal servo connector delivers the throttle signal
to the ESC, plus the ESC can send telemetry data like voltage and current
back to the receiver. The AR8360T receiver throttle port (Channel 1 port only)
will automatically detect when a Smart compatible ESC is connected. ESCs
with Smart and IC series connectors can also pass along battery data from
compatible Spektrum Smart batteries. Spektrum Avian
™
ESCs are compatible
with the AR8360T receiver for Smart Technology features.
For Smart to function you must have a Smart ESC paired with a Smart
telemetry receiver, and a Spektrum DSMX transmitter with telemetry. An update
for your transmitter may be required for Smart features. See www.spektrumrc.
com to register and update your transmitter.
If a standard ESC or servo is plugged into the throttle port on the AR8360T
receiver, the throttle port will operate normally (PWM signal) like any
conventional RC system.
XBUS Port
SRXL2 Port
Bind Button
Smart Port
Voltage Sensor Port
AR8360T
Type DSM2/DSMX 8 CH AS3X Telemetry Receiver
Application Air
Channels 8
Receivers 1
Remote Receiver
(not included)
SRXL2
™
Remote Receiver Optional
[SPM9747, SPM4651T]
Modulation DSM2/DSMX
Telemetry Integrated
Bind Method Bind Button, Bind Plug
Failsafe Yes
Band 2.4GHz
Dimensions (LxWxH) 49 x 30 x 15mm
Weight 16g
Input Voltage 3.5–9V
Resolution 2048
Antenna Length 155mm and 186mm
Specifications
