KEY PART NAME MATERIAL PART NUMBER REMARKS
Enclosed Spring Chamber
29 Spring Chamber Steel WAL7-40529-0 - - - -
Adjusting Handle
30 Handle and Hub Assembly Steel WAL8-09774-0 - - - -
31 Adjusting Stud Spacer Brass WAL4-05600-0 - - - -
32 Thrust Bearing Steel WAL5-00552-0 - - - -
33 Guide Standard Locknut Steel WAL5-03016-0 - - - -
34 Cross Bar Steel WAL4-00434-0 - - - -
35 Guide Standard Spacer Brass WAL4-04936-0 - - - -
36 Support Standard Nut Steel WAL5-02942-0 - - - -
37 Adjusting Stud Assembly - - - - WAL7-40550-0 - - - -
38 Spring Yoke Cast iron WAL4-06173-0 - - - -
39 Support Standard Steel WAL4-05223-0 - - - -
40 Guide Standards Steel WAL4-05221-0 - - - -
Wall Bracket
41 Wall Bracket Cast iron WAL4-01029-0 - - - -
42 Diaphragm Bolt Steel WAL5-04766-0 Note 1
Diaphragm Stud Steel WAL5-05462-0 Note 2
10 Diaphragm Nut Steel WAL5-02871-0 Note 1
Diaphragm Nut Steel WAL5-02845-0 Note 2
Flanged Inlet
44 Gasket Steel Asbestos WAL5-02370-0 - - - -
45 Flange Assembly - Female Steel WAL7-43516-0 See item 12
46 Flange Assembly - Male Steel WAL7-40535-0 - - - -
13 Stud Steel WAL5-05490-0 - - - -
10 Nut Steel WAL5-02845-0 - - - -
Composition Disk
47 Stem Stainless steel WAL4-05381-0 B
48 Seat Ring Stainless steel WAL4-04060-0 B
49 Composite Disk Assembly Brass WAL7-53512-0 B
A - Recommended Spare Parts
B - These parts furnished in Repair Kit (Steam screen):
Stainless steel Disk: Cast iron and Bronze (WAL8-09157-0), Carbon steel (WAL8-10357-0)
Composite Disk: Cast iron and Bronze (WAL8-09158-0), Carbon steel (WAL8-10380-0)
Note 1: Applies to Iron and Bronze Body Pilots
Note 2: Applies to Steel Body Pilots
Use Pilot Setting instructions WAL9-98165-0
Table 7. Type D2 Pilot Parts List (Figure 7) (continued)
11
