KEY PART NAME MATERIAL PART NUMBER QUANTITY REMARKS
1 Adjusting Nut Steel WAL05-02874-00 2 - - - -
2 Spring Yoke Iron WAL05-06183-00 1 - - - -
3 Standard Steel WAL04-05219-00 2 - - - -
4 Adjusting Spring Steel See Table 1 1 - - - -
5 Spring Button Steel WAL04-01040-00 1 - - - -
6 Cowl Cast Iron WAL04-01508-00 1 Cast Iron Body
Cowl Steel WAL04-1592-00 1 Steel Body
7* Diaphragm Screw Steel WAL04-04822-00 1 - - - -
8* Pusher Plate Steel WAL04-03718-00 1 - - - -
9* Valve Spring Inconel
®
WAL05-04985-00 1 - - - -
10 Bushing Stainless steel WAL04-01080-00 1 - - - -
11* Seat Ring Seco Metal WAL04-04057-90 1 - - - -
12 Body, Bushing, Plug Cast Iron WAL07-03514-00 1 - - - -
Body, Bushing, Plug Steel WAL07-04267-02 1 - - - -
13* Gasket Blugard WAL05-02378-01 1 Cast Iron Body
Gasket Flexitalic WAL05-11718-00 1 Steel Body
14 Blind Flange Cast Iron WAL04-02151-00 1 - - - -
Blind Flange Steel WAL04-11678-00 1 - - - -
15 Diaphragm Nut Steel WAL05-02871-00 12 Cast Iron Body
Diaphragm Nut Steel WAL05-02845-00 24 Steel Body
16* Pressure Plate Steel WAL04-06979-00 1 - - - -
17* Diaphragm Stainless steel WAL04-01623-00 3 - - - -
18 Diaphragm Bolt Steel WAL05-04764-00 12 Cast Iron Body
Diaphragm Stud Steel WAL05-05490-00 12 Steel Body
19* Stem Stainless steel WAL04-05229-00 1 - - - -
20* Screen Stainless steel WAL04-04700-00 1 Steam Service
Screen Stainless steel WAL04-04701-00 1 Water Service
21* Disk Seco Metal WAL04-01772-90 1 - - - -
22* Stem Nut Steel WAL05-02888-00 2 Steam Service
Stem Nut Brass WAL05-02886-00 2 Water Service
23 Blind Flange Bolt Steel WAL05-04803-00 4 Cast Iron Body
Blind Flange Bolt Steel WAL05-11719-00 4 Steel Body
* These parts furnished in Repair Kit.
REPAIR KIT MATERIAL PART NUMBER
Repair Kit - Hard Cast Iron Pilot WAL07-04164-00
Repair Kit - Hard Steel Pilot WAL08-10375-00
Repair Kit - Soft Cast Iron Pilot WAL08-08556-00
Repair Kit - Soft Steel Pilot WAL08-10379-00
Table 3. Repair Parts Kit
Table 4. Types D and D5 Series Parts List
Inconel
®
is a mark owned by Special Metals Corporation.
