KEY PART NAME MATERIAL PART NUMBER QUANTITY REMARKS
Locking Device
35 Padlock Brass WAL05-03204-00 1 - - - -
36 Lock Bar Steel WAL04-00436-00 1 - - - -
37 Spring Yoke Assembly Iron WAL07-43507-00 1 - - - -
Wall Bracket
15
Diaphragm Nut Steel WAL05-02871-00 1 Iron Body
Diaphragm Nut Steel WAL05-02845-00 4 Steel Body
38 Wall Bracket Cast Iron WAL04-01029-00 4 - - - -
39
Diaphragm Bolt Steel WAL05-04766-00 4 Iron Body
Diaphragm Stud Steel WAL05-05462-00 8 Steel Body
Composition Disk
25* Disk Assembly Brass WAL07-53512-00 1 - - - -
26* Stem Stainless steel WAL04-05381-00 1 - - - -
27* Seat Ring Stainless steel WAL04-04060-00 1 - - - -
Enclosed Spring Chamber
28 Adjusting Screw Steel WAL05-04860-00 1 - - - -
29 Locknut Steel WAL05-02942-00 1 - - - -
30
Spring Chamber Iron WAL04-01393-00 1 - - - -
Spring Chamber Bronze WAL04-01395-00 1 - - - -
Spring Chamber Steel WAL04-01394-00 1 - - - -
Enclosed Spring Chamber Kit Cast Iron WAL08-01868-00 - - - -
Adjusting Wheel
31 Handwheel Aluminum WAL04-12985-01 1 - - - -
32 Adjusting Screw Steel WAL04-04752-02 1 - - - -
33 Locknut Steel WAL05-02942-00 1 - - - -
34
Yoke Cast Iron WAL04-06170-00 1 Iron Body
Yoke Ductile Iron WAL04-06167-02 1 Steel Body
Handwheel Kit Cast Iron WAL08-01867-00 - - - -
Vacuum Spring Assembly
40 Floating Plate Iron WAL04-03710-00 1 - - - -
41 Vacuum Spring 302 Stainless steel WAL05-05055-00 1 - - - -
42 Valve Spring Inconel
®
WAL05-09353-00 1 - - - -
*These parts furnished in Repair Kit.
Table 5. D Series Options Parts List
Inconel
®
is a mark owned by Special Metals Corporation.
