Spheros Thermo 230 User Manual (English)

Other manuals for Spheros Thermo 230

Workshop Manual98 pages

Installation Instructions106 pages

Warranty Manual10 pages

Questions and Answers:

J
jennifermaciasAug 1, 2025
What to do if Spheros Thermo 230 Water Heater operation stops due to insufficient heat dissipation?
- C
  Christopher HolmesAug 1, 2025
  If the Spheros Water Heater stops because heat exchangers don't dissipate enough heat, it could be due to several reasons. The rate of flow might be too low because of air in the heater, heat exchangers, or system sections. Valves might be throttled, contaminated, or closed. There could be contamination in the system, especially in areas of restricted flow. The circulating pump's rate of delivery might be insufficient, possibly due to air in the pump housing. Check the wiring colors to ensure the correct sense of rotation (black + / brown -). Insufficient anti-freeze can cause slushing. Excessive system resistance, especially when cold, or a defective circulation pump could also be the cause.
A
Adriana FitzgeraldAug 10, 2025
Why is there no fuel delivery to my Spheros Water Heater?
- S
  spencerpatriciaAug 10, 2025
  If there's no fuel delivery to your Spheros Water Heater, several issues could be at fault. The fuel tank might be empty. Check for kinked, closed, contaminated, or leaking fuel lines. Paraffin deposits or water might be captured in the fuel filter or fuel lines. The vent in the tank could be clogged. Ensure the fuel lines aren't interchanged. The fuel filter or the fuel screen in the pump could be contaminated.
C
christopher95Aug 21, 2025
What to do if Spheros Water Heater operating light is off and there is no heat?
- N
  nortonleslieAug 21, 2025
  If the operating indicator light is not on and there is no heater operation in your Spheros Water Heater, it indicates a fault in the electrical system. Check if Fuse F2 or F3 has blown. If the heater operation is normal, but the operating indicator light is out, this also indicates a fault in the water system and the circulation pump is not operating.

Spheros Thermo 230 Specifications

General

Brand	Spheros
Model	Thermo 230
Category	Water Heater
Language	English

Summary

Service and Safety Instructions

Switch off auxiliary heating before refuelling

Turn off the auxiliary heating system before refueling the vehicle.

Heater Prohibitions

Lists conditions and locations where the heater must not be operated.

Prohibited at Refueling Points

Do not operate the heater at filling stations or other refueling points.

Prohibited in Flammable Atmospheres

Avoid operation where flammable vapors or dust may form.

Heater Restrictions and Requirements

Prohibited Near Flammable Materials

Do not operate near flammable materials like dry grass, leaves, or paper.

Prohibited in Enclosed Areas

Avoid operation in enclosed areas without ventilation.

Prohibited with Obstructed Exhaust

Do not operate if the exhaust outlet is blocked by soil or snow.

Avoid High Storage Temperatures

Do not expose the heater to temperatures exceeding 110°C to prevent electronic damage.

Maintain Antifreeze Concentration

Operate only with at least 20% antifreeze in the heating system water.

Use Correct Fuel and Voltage

Operate using the specified fuel type and rated voltage shown on the model plate.

Shut Down on Malfunctions

Shut down immediately by removing the fuse for smoke, noise, or fuel odors.

Post-Malfunction Inspection

Do not reuse the heater until inspected by trained personnel after a malfunction.

Regular Operation Requirement

Operate for 10 minutes monthly, especially when cold, to maintain function.

Annual Expert Inspection

Have the heater inspected by an expert at the start of the cold weather season.

Liability Claims

Non-Compliance Voids Liability

Failure to follow instructions or using non-genuine parts voids liability and approvals.

Claims Require Instruction Adherence

Liability claims are valid only if all servicing and safety instructions have been followed.

Heater Operation

Standard Timer Overview

Explains the components and indicators of the standard digital timer.

Standard Timer General Features

Outlines the timer's capabilities like pre-setting, wake-up alarm, and display behavior.

Timer Pre-setting Capability

The timer allows pre-setting heater operation up to 7 days in advance.

Multiple Programmable Start Times

Allows programming 3 start times, with only one active at a time.

Wake-up Alarm Function

The digital timer includes a wake-up alarm feature.

Timer Display on Ignition On

Displays current time and day of week when vehicle ignition is on.

Timer Illumination When Active

Display and buttons illuminate when the heater is switched on.

Initial Time and Weekday Setting

After power connection, set the current time and weekday as symbols flash.

Standard Timer Operation

Explains how to adjust timer settings using buttons and mentions fast time-setting mode.

Heater Switching On

Details manual and automatic methods for switching the heater on.

Timer Settings and Control

Heater Switching Off

Describes manual, automatic, and runtime-based methods for switching the heater off.

Setting Time and Day of Week

Procedure for setting the current time and day of the week on the timer.

Viewing the Time

Instructions on how to view the current time when the ignition is switched off.

Programming Heater Starting Time

Guide to setting specific heater start times and days using memory locations.

Recalling/Erasing Preset Times

How to recall stored start times or erase them from memory.

Programming Duration of Operating Time

Instructions for setting the desired operating time for the heater (10-120 minutes).

Setting the Remaining Operating Time

How to adjust the remaining operating time while the heater is running.

Setting the Wake-up Time

Procedure for programming a wake-up alarm time on the digital timer.

Recalling/Erasing the Wake-up Time

How to view or delete the programmed wake-up alarm time.

Remote Control Options

Mentions the possibility of using an optional external 'instant heating' button.

Troubleshooting

General Troubleshooting Steps

Initial checks for malfunctions: fuses, electrical connections, and consulting a dealer.

Fault Lock-out Identification

Explains coded flashing signals via the indicator light for fault identification.

Heater Turns Off Automatically

Lists common causes for automatic shutdown and their remedies.

Troubleshooting Causes and Remedies

Details specific faults like no combustion, flame failure, overheating, low voltage, and blocked ducts.

Fault Code Display

Fault Code Appearance

Fault codes appear on the digital timer display when a malfunction occurs.

Fault Codes Table

Lists fault codes (F01-F12) and their corresponding malfunctions.

Deactivating Heater Lock-out Mode

Procedure to deactivate the heater lock-out mode by power cycling during startup.
