Assembly Instructions
MSW from M72 to M140
©Spieth
Proprietary
notice
ISO 16016
Previous document: ma-mswg-en1604
See
www.spieth-me.de/english/service-download/catalogue-instructions/
For any questions, requests or suggestions, please contact
info@spieth-me.de
1 Information about Spieth Locknuts
1.1 General information
Spieth locknuts are precision parts and require careful handling. Follow the information in these assembly
instructions and the operating instructions. Failing to comply with them may significantly impact functionality and
service life.
To apply the locking force, use only original Spieth clamping screws. Do not actuate the clamping screws until the
locknut thread has been fully screwed onto the spindle thread. Otherwise, damage such as ductile deformation
may occur on the locknut and render it unusable. Spieth-Maschinenelemente GmbH & Co. KG assumes no liability
for damage from improper handling, incorrect installation, or unauthorised structural changes.
1.2 Safety notices
Spieth locknuts are intended for use on threaded spindles. Please follow all relevant safety notices.
Caution!
Any work carried out with or on the locknut needs to follow the "safety first" guideline!
During operation, keep your hands away from the working area of the locknut!
Prior to any assembly work, switch off all machine drives!
Secure the machine against accidental power-up!
Prior to commissioning the machine, install all safety devices!
Only expert personnel are allowed to perform assembly work on Spieth locknuts. Using Spieth locknuts is only
admissible according to specifications. Spieth-Maschinenelemente GmbH & Co. KG assumes no liability for
violations of the operating instructions or safety notices. This also applies to incorrectly interpreting or circulating
these notices and to incorrect assembly or maintenance.
The locknuts described here are state of the art at the time these assembly instructions are printed. Subject to
changes based on evolved technologies. For international deliveries, follow the safety regulations applicable in
the target country.
