PRODUCT GUIDE
2
KETTLE
PRO TIPS:
• All threaded NPT fittings require pipe tape for a leak free seal. You’ll want
to put 3-4 wraps of pipe tape on the threads in a clockwise direction. If your
fitting is not oriented correctly after tightening a combination of tightness
and amount of pipe tape will need to be adjusted.
• Make sure the element is plugged in and the power cord is fully twisted into
position. If not, the resistance will increase and can cause the plug to melt.
ITEM DESCRIPTION QTY
A
MNPT x QC Fitting 2
B
3pc Ball Valve 2
C
5/8” Quick Connect Fitting 2
D
Side Pickup Tube 2
E
Heating Element 1
F
1.5” TC Gasket 1
G
1.5” TC Clamp 1
H
Temp Probe 1
G
F
D
E
H
C
B
A
