Slide the screw through the base, and
side the nut in so it rests in the slot.
Tighten with a screwdriver, do not over
tighten.
Do the same on the other side of the
assembly. Slip the nut in the slot, and
slide the screw up from the bottom
Tighten with a screwdriver, do not over
tighten.
You will be using these nuts and screws to hold secure
the motor mount assembly to the bottom plate.
3/8” 4-40 screws
4-40 nuts
