Laser cut acrylic, electronics, hardware parts
Motor mount - wire side Motor mount - Arm side
2x #4 weld nuts
4x 4-40 nuts
2x #4 washers
4x 3/8” 4-40 screws
2x 1” 4-40 screws
#12 washer
Switch nut
and washer
#2 screw and
washer
Battery holder
PCB
220 ohm resistor
100 ohm resistor
Switch
Motor
Base washers
Arm
Base
2 Color LED
Snap switch
Screw terminals
Some of the steps in the build of this kit require the snipping component legs. If
you’re building this kit on your own, or with a someone else, we STRONGLY
recommend whoever is present is wearing safety glasses. When the legs are
snipped, the can fly off in unpredictable directions, at a high speed. Also, be sure to
follow the safety instructions that came along with your soldering iron. Wash your
hands after handling solder. Especially before eating. Be safe, and enjoy.
!
