Spimbey 2001 - Assemble Beams (Step 3)

Add extra washers if needed
for proper engagment with T-nut
1/4 x 4.25” Hex Bolt X1
1/4 Lock Washer X1
1/4 Flat Washer X1
1/4 T-Nut X1
From this side in end holes X4
1/4 x 5.50” Hex Bolt X1
1/4 Lock Washer X1
1/4 Flat Washer X1
From this side in end holes X4
1/4 T-Nut X1
From this side
40.19” [102.1]
14.00” [35.6]
Note hole locations
ASSEMBLE BEAMS
3
1. Locate and install parts as shown.
Parts Required:
224 X 1
240
