Spimbey 2001 - Beam Plates (Step 2)

BEAM PLATES
2
5/16 x 1.50” Hex Bolt X4
14.00”
[35.6]
5/16 Lock Washer X4
5/16 Flat Washer X4
Note hole locations
Important - insert bolt into END holein
plate and hole in beam
DWERWKHQGVRI
EHDP
X4
This hole lines up with
hole in beam
5/16 T-Nut X4
40.19”
[102.1]
1. Locate and install as shown.
Parts Required:
300 Plate X 4
300
4x
