Spimbey 2001 - Assemble Frames & Beams (Step 5)

1. Attach parts as shown
Parts Required:
Beam Assembly X 2
A-Frame Assembly X 8
ASSEMBLE FRAMES & BEAMS
5
5/16 x 2.00” Hex Bolt X2
5/16 Flat Washer X2
5/16 x 4.25” Hex Bolt X2
5/16 Flat Washer X2
5/16 T-Nut X2
5/16 Lock Nut X2
5/16 Flat Washer X2
IMPORTANT  ENSURE THREADS
ARE FLUSH OR EXTEND PAST LOCK NUT
Bolts in these holes
