Spimbey 2004 - Sandbox Seats, Slide Block, and Tarps

21
1. Attach parts as shown.
Parts Required:
119 X2
145 X2
SANDBOX SEATS - SLIDE BLOCK
1. Attach parts as shown.
Parts Required:
119 X2
145 X2
From under the deck, locate 145
against deck board, rail and joist.
Attach from TOP of deck through
deck board at measurements shown
#8 X 1.38 Wood Screw X4
2 - Screws per board
Slide
Slide
#8 x 2.50 Wood Screw X8
Flush with rails
9.500 [241.3]
From edge
of deck
7.000 [177.8]
Between screws
2.750
[69.9]
)URPHGJHRIGHFN
4.000 [101.6]
Between screws
119
2x
145
2x
