1. Attach the tarps as shown. Two people recommended
1. Attach the tarps as shown. Two people recommended.
Parts Required:
Table Tarp with Snaps X1
Wall Tarp with Snaps X1
33.875 [860.4]33.875 [860.4]
0.750 [19.1]
Step 1 - Mark at the measurements shown.
Install one threaded stud.
Step 2 - Attach the tarp to the middle snap,
pull tarp to sides and tap the snaps to leave a mark
in the wood. Install threaded studs at marks.
Step 3 - With tarp attached at top, pull tarp down
firmly and tap the snaps to leave a mark in the
wood. Install threaded studs at marks.
Level
Swing Beam Side Tarp
(On outside of wall)
Hold tarp centered in opening. Snaps are located
.75 [19.1] onto table rail.
Tap snaps at TOP ONLY to leave marks in
the wood. Install threaded snaps at each mark.
Attach tarp across top onto snaps.
Pull tarp down and sideways firmly.
Tap snaps to leave marks in the wood.
Install threaded snaps at each mark
Center in
opening
.
0.750 [19.1]
X8
X14
15.625 [396.9]
To Next Page
