INSTALLATION
A cut-out should be prepared in the worktop, see appropriate appliance diagram. Heat
barriers must be fitted to the front and back edges of the cut-out as shown on section A-A.
The appliance should be fixed in position using countersunk woodscrews fitted through the
pan rest clips as shown.
MODELS 756/854F/H250F - A minimum depth of 185mm from the top of the worktop
surface must be provided for the separate grill compartment. The front of the cupboard
should be cut-out as shown – see installation details. Slide the grill box into place and fix it
to the sides of the cupboard cut-out with 2 screws on each side.
MODELS H200F/H400F - A minimum depth of 60mm from the top of the worktop surface
must be provided for the hotplate
A direct distance of 200mm must exist between the edge of the appliance burners and any
combustible material, unless protected by a layer of non-combutible material. All
combustible materials such as curtains and shelves must be kept well clear of the
appliance. Any fitments such as a cupboard above the unit must have a minimum
clearance of 500mm between the fitment and the top of the Panrest.
In the case of appliances that do not have grills fitted, the underside of the appliance must
be shielded. It is recommended that the shield be fabricated from non-combustible
material, but if the enclosure is manufactured from combustible material, then a minimum
air space of 100mm must exist between the material and the lowest part of the appliance.
This air space MUST be well ventilated.
Appliances fitted with a grill require that a grill compartment be created below the cut-out
as shown – see installation details. The compartment must be completely lined with a non-
combustible material such as aluminium or stainless steel. The grill compartment must
have ventilation holes at the compartment floor level and additionally include an escape
route to the outside to prevent the accumulation of unburnt gasses. Any cabinets beneath
the grill compartment must be sealed to prevent the ingress of unburnt gas.
Connection
An 8mm gas inlet point is provided on the underside of the appliance. It is recommended
that the appliance be connected by copper tubing, a rubber connection must not be used.
After connection the appliance must be tested for soundness.
It is important that the regulator should be set to the correct pressure for the type of gas
being used. Excessive pressure must not be permitted.
