6.3 Commissioning - full
6.3.1 Main menu structure
MODE
Allows the user to set their own password.
Allows the user to view and change the valve status OFF, OPEN
or AUTO.
Allows displayed units to be configured:-
Temperature in °C or °F, multiple timer priority and recovery
time to allow blowdown vessel contents to cool.
Configures the link to switch box on the bottom blowdown valve.
Configures the output communications link.
Sets actual year, date and time.
Allows the user to set up the first blowdown sequence
Duration, Start, Repeat, Stop and Days.
Allows the user to set a second sequence, if required.
For example a different blowdown duration and frequency may
be required over weekends. Not available if, Timer 1 not used or
alldays are used.
As Timers 1 and 2 if required.
Not available if Timer 2 not used or all days are used by
Timer 1 or timer 2
Warns if the valve does not lift off its seat in a given time.
Set to OFF if the valve is to be opened manually without the alarm
sounding. Latch / non latching option.
Allows the product display and functions to be tested.
Indicates the software version installed in the product.
