6.3.9 ALARM sub-menu
6.3.10 TEST sub-menu
Only shows if switch is fittted, set On or Off.
ON - Alarm will latch until commissioning mode is entered.
OFF - Alarm will only sound until the alarm condition is
removed.
Note: If switch is fitted, the timer will latch an alarm if the
valve fails to close. This cannot be disarmed.
Only shows if the switch is FITTED. Set ON or OFF.
ON - The alarm will sound if the valve fails to lift within
the time set in INPUT / LIFT.
OFF - No alarm.
Note: If ON selected, alarm will operate if MODE set to
OPEN, or if valve is manually opened.
Tests outputs:
VALVE - Opens or closes valve manually.
ALARM - Energises / de-energises alarm relay manually.
CANCEL - Select cancel or wait 5 minutes to return to
automatic control.
Tests inputs:
INT TEMP - Shows maximum internal temperature
of the electronics.
LINK - Detects if other boilers are blowing down. Will
show 'ON' if MODE-OPEN is selected.
SWITCH - Detects if the switch is open or closed.
Tests the display:
- (black on white or white on black).
- Allows the user to visually identify faulty pixels on the
display.
