45
10.5 Battery (Clock calendar)
Manufacturer TADIRAN
Manufacturers part number SL-360 / PT
Spirax Sarco part number 0965057
Type
AA (PCB tagged) Lithium Thionyl Chloride
(Lithium content 0.65 g)
Voltage 3.6 V
Capacity 2.4 Ah minimum
Temperature range 0 - 70°C minimum
Shelf life 10 years - With battery switch OFF @ Tamb: 25°C
Working life 10 years - Mains power on 35 hours / week @ Tamb: 55°C
10.6 Cable / wire and connector data
Mains and signal connector
Termination
Rising clamp plug-in terminal blocks with screwed
connectors
Cable size 0.2 mm² (24 AWG) to 2.5 mm² (14 AWG).
Stripping length 5 - 6 mm
Please note: Use only the connectors supplied by Spirax-Sarco Limited – Otherwise Safety
and Approvals may be compromised.
Switch box and Lockout (link) circuit
Type High temperature
Shield type Screened
Number of cores 2
Gauge 1 - 1.5 mm² (18 - 16 AWG)
Maximum length 100 m (328 ft)
Recommended type Prysmian (Pirelli) FP200, Delta Crompton Firetuf OHLS
RS485 communication cable / wire
Type EIA RS485 Twisted pair
Shield type Screened
Number of pairs 2 or 3
Gauge 0.23 mm² (24 AWG)
Maximum length 1 200 m (4 000 ft)
Recommended type Alpha wire 6413 or 6414
LAN Category 5 or Category 5E ScTP (screened), FTP (foil) or STP (shielded) cable can be
used, but limited to 600 m.
