Spirax Sarco LCS3050 - Installation in Control Cabinet

IM-P693-06 EMM Issue 1
8
LCS3050 Low Water Level Switch for two probes
3.2 Installation in control cabinet
The level switch LCS3050 is clipped onto the support rail 7 type TH 35, EN 60715 in the control cabinet.
Name-plate
LCS3050
Alarm Signal
24 VDC
100 mA
CEP
Low Water Level Limiter
Tamb = 55°C (131°F)T
IP 40 (IP20)
7 W
0525
250V
T 2,0A
TÜV.SWB.XX-XXX
Level Switch
Niveauschalter
Commutateur de niveau
20
29
21
30
3sec.
Functional safety
IEC 61508
SIL 3
10 µS/cm
9
2
LP 40
1
2
3
1
3
4
5
10
11 12
13
16
17
23
24
26
27
LCS3050
MIN
24 V
±20%
M 0,5A
4-393313-02
+
MADE IN GERMANY
See installation
instructions
Betriebsanleitung
beachten
Voir instructions de
montage
24 V=
AL 1
AL 2
AL 1
AL 2
+
_
_
AL 1 AL 2
1
Safety note
2
Wiring diagram
3
Manufacturer
4
Type designation
5
Supply voltage/Protection
6
Ambient temperature / sensitivity
7
Safety circuit
8
Wire link,provided on site
9
Fuse, provided on site
10
Type approval no.
11
Disposal note
Fig. 3
1
2
3
6
5
8
7
4
9
10
11
TÜV.SWB.XX-XXX
