IM-P372-27 CTLS Issue 2
7
LSB31, LSB32, LSB33, LSB34, LSB71, LSB72, LSB73 and LSB74 Limit Switch Boxes for BVA300 Series Actuators
Note: Before actioning any installation observe the 'Safety information' in Section 1.
3.1 General installation
The box is supplied with a stainless steel mounting bracket, which may be mounted on any actuator having
a NAMUR VDI/VDE 3845 interface.
-
Manually turn the box shaft to align it with the actuator before engaging the drive shaft.
-
Fasten the box to the actuator using the bolts provided.
3.2 Cam adjustment - If required
All units are supplied with 0º - 90º cam adjustment:
-
Loosen the 4 cover screws and remove the cover.
-
Readjust the cams to the position required.
3. Installation
