IM-P357-29 CTLS Issue 14
19
Fig. 8
Front and rear clamps (13 and 14)
Clamp locking screws (26 and 27)
Fig. 7 Assembly of actuator adaptor, valve adaptor and connectors
Actuator spindle (6)
Lock-nut (25)
Connector (10)
Front and rear clamps
(13 and 14)
Collar (12)
Valve spindle
Valve adaptor
(11)
