Page #8 background imageLoading...
Page #8 background image
IM-P316-03 CTLS Issue 14
8
2.5 Materials
No. Part Material
1 Body Bronze BS EN 1982 CC491KM
2 Nozzle
DN15
and
DN20
Stainless steel BS 970 431 S29
DN25
to
DN50
Stainless steel BS 3146 Pt2 Gr. ANC2
Sanitary
connection
Stainless steel ASTM A276 316L
3 Disc Stainless steel ASTM A276 316L
4 Lever housing Bronze BS EN 1982 CC491KM
5 Spring Chrome-vanadium alloy steel BS 2803 735 A50 HS
6 Stem guide Brass BS 2872 CZ 121
7 Spring end plate Brass BS EN 12165 - CW617N
8 Stem Stainless steel BS 970 431 S29
9 Adjustment screw Brass BS 2874 CZ 121
10 Lever Zinc plated SG iron
11 Pivot pin Stainless steel AISI 304
12 Circlip Stainless steel BS 2056 316 S42
13 Adjuster lock-nut Brass BS 2872 CZ 121
14 Soft seal disc
Stainless steel/Nitrile ASTM A276 316 /bonded Nitrile 4490 (90 IRHD)
Stainless steel/EPDM ASTM A276 316 /bonded EPDM 2064 (75 IRHD)
Stainless steel/Viton ASTM A276 316 /bonded Viton F81 (85 IRHD)
15 Sealed cap Bronze BS EN 1982 CC491KM
16 Cap seal Nitrile BS 2874 CZ 121
17 Skirt Brass BS 2874 CZ 121
18 Grub screw Steel
19 Ball Stainless steel
