9
Operating instructions
While unpacking your appliance, check that the parts are complete, and
that there is no damage due to transportation.
Make sure that the mains voltage corresponds to the voltage indicated
on the appliance specification plate.
• Check the stability of your vacuum cleaner. Use the 2 steering
wheels with a braking system (11). To activate the brake, press
the front wheel lug. The wheel is blocked. To release the brake, raise
the lug.
• Connect the suction pipe (15) to the vacuum cleaner’s bayonet
connection (14), as well as to the electrical tool you are using
(example: jointer, drill,…)
• Connect the vacuum cleaner’s electric cable (6) to the mains.
Caution ! If an electrical tool had been connected to the vacuum
cleaner socket (2b), check that this tool is switched off.
• Adjust the suction capacity using the airflow control (2d).
• Start the vacuum cleaner by moving the switch to the position of
your choice:
Position 0: stop
Position I: Start in manual mode
Position A: Automatic Start/Stop by the electrical tool connected
to the socket (2b)
Position AC: Automatic Start/Stop by the electrical tool
connected to the socket (2b),
with automatic cleaning of filters
every 2 minutes of actual work
.
SWITCH (2a)
Start/stop the vacuum cleaner with the switch (2a) located on the
upper part (1) of the vacuum cleaner.
0 = vacuum cleaner > stop <
I = vacuum cleaner > start < , (manual operation)
A = in start order for automatic start/stop
(the vacuum cleaner is switched on and off by the electrical tool
connected to the socket (2b))
AC = in start order for automatic start/stop
(the vacuum cleaner is switched on and off by the electrical tool
connected to the socket (2b))
Before putting
the appliance
into service
Putting
the appliance
into service
Electrical
control table (2)
G
