SPIT SD 160 - TECHNICAL SPECIFICATIONS

3
TECHNICAL SPECIFICATIONS
Nominal voltage 230 V
 2000 W
Rated current 9.25 A
Frequency 50-60 Hz
Max. dry drilling Ø 181 mm
 131 mm
Shank ½" and 1 ¼"
Protection class I
Weight 6.2 kg
Dimensions 405 x 265 x 112 mm
Interference suppression according to EN 55014 and EN 61000
Gear / speed Idle speed Load speed
1st speed 0-660 rpm 0-900 rpm
2nd speed 0-1550 rpm 0-2200 rpm
3rd speed 0-3300 rpm 0-4600 rpm
 60 mm
 ¼"

Mechanical overload clutch
Thermal overload protection
Noise and vibration
The indication of noise emission is measured after DIN 45 635, p art 21.

protectors must be used.

Conrmation declaration
We declare in sole responsibility that the product type Spit SD 160 referred to in this



EN 60 745, EN 55 014, EN 61 000,
according to the regulations 73/23/EWG, 2004/108/EG, 2006/42/EC
Paul van Beek Ruben Bernaert
General Manager Product Manager
ITW Heger
Industriepark
Cardijnlaan 3
BE-8600 Diksmuide
Belgium
