4
FUNCTIONAL DESCRIPTION
Supply
(type Gardena), quick connection, telescopic centring device, instruction manual and safety
manual in transport case.
Application for intented purpose
The diamond drilling machine SD 160 is indented only for professional use and may be
used only by instructed personnel.
diameters above 61 mm and drilling in 1st gear, it is a must to use a suitable drilling rig.
and stone and for dry cutting of bricks, sand-lime bricks and pore concrete.
Electrical connection
The SD 160 is designed according to protective class II. For the user’s safety, the tool may
table underneath). A too small cross section may cause malfunction of the tool.
Recommend minimum cross sections and maximum cable lengths:
Mains voltage 230 V
Cross section in mm
2
1.5 2.5
Cable length 50 m 80 m
requirements of the tool’s nameplate.
The tool includes a start-up speed limiter to prevent fast explosion fuses from
unintended responding.
Additional handle
