SPL 500 Series - Specifications; Installation

2 BiG – 500 series BiG – 500 series 3
Introduction
Developer
Wolfgang Neumann
Version 1.0 – 05/2022
This manual contains a description of the product. In no way it represents a guarantee
of particular characteristics or results of use. The information in this document has
been carefully compiled and veried and, unless otherwise stated or agreed upon,
correctly describes the product.
Specications are subject to change without notice.
Specications
General
Frequency range (-3 dB): 10 Hz - 100 kHz
Common mode rejection (1 kHz, 0 dBu ): > -82 dBu
THD + N (0 dBu): 0.03%
Noise (A-weighted): 92.3 dBu
Dynamic range: 113 dB
Input (balanced)
Impedance: 20 kohms
Maximum input gain: +21 dBu
Output (balanced)
Impedance: 150 ohms
Maximum output gain: +21 dBu
Scope of Delivery
BiG module, 500 series
Manual
Measurement & Weight
Double-slot module, series 500
Weight: 1.98 lbs (0.9 kg)
Please keep the original packaging. In a service case the original packaging ensures a
safe transport.
Installation
Installation into a 500 series rack:
• Please read the manual that comes with the 500 series rack. You should receive all
necessary information for the installation process.
• For the installation or exchange of BiG, your 500 series rack should be switched
o and the power cable should not be connected.
• Insert the BiG module into two adjacent free slots of your rack. Make sure the con-
nectors of the BiG is precisely aligned with the rack connectors.
• Press the BiG module carefully into the rack connectors and tighten the screws.
• Connect the BiG module with your audio environment using the connections from
your 500 series rack.
• Insert the power cable to the 500 series rack and switch it on.
