SPL Crossover - MID-HI Section; X-OVER On;Off; X-OVER | Hz; ROLL-OFF

12
MID-HI Section
MID-HI Section
In the MID-HI section you control the frequency and the roll-off of the top speaker crossover.
X-OVER On/O
If you want to drive your top speakers full range, set the X-OVER On/Off switch () to off. The
MID-HI crossover is switched off and the input is passed to the MID-HI OUTPUTS() with-
out any processing.
X-OVER | Hz
Select the X-OVER frequency (, , , ,  or  Hz) with the MID-HI X-OVER
switch().
ROLL-OFF
The roll-over of the MID-HI section can be switched between  dB (Butterworth) and 
dB (Linkwith/Riley) per octave with the MID-HI ROLL-OFF switch ().
