AMP CTL (Standby / Amplier Control)
AMP CTL (Standby / Amplier Control)
AMP CTL stands for 'amplifier control'. It is essentially a V trigger to switch con-
nected units from standby to on and vice versa.
If you own an SPL device supporting AMP CTL output(s) you can trigger standby and
operation of the Crossover. Therefore connect the AMP CTL output of the SPL device
to the Crossover's AMP CTL IN ().
The Crossover has four trigger AMPCTL Outputs () to switch on up to four power amplifiers simultaneously. If
the Crossover is triggered via its AMP CTL IN, the connected power amplifiers are triggered too.
You may also use other V trigger controller. The Crossover is in operation mode when a switching voltage of 
Volt DC is applied to the AMP CTL input. As soon as the  Volt DC is removed, the Crossover switches back to
standby.
SPL devices are equipped with mini jack connectors. Use cables with mono mini jack plugs (/", .mm) where
the tip is plus and the sleeve is minus.
1 3
2 4
Connect to
SPL Performer
Amplifier (s)
for remote
power on/off
AMP CTL/ 12V TRIGGER
AMP CTL/ 12V TRIGGER
IN OUT OUT
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 45 W
Tip
Sleeve
