Welcome
and thank you for choosing the SPL Crossover.
The SPL Crossover is a high-end active analog -way crossover that will perfectly team up your subwoofer(s) with
your top speakers. You can tune crossover frequencies, align the phase response and set levels all in the analog
domain.
VOLTAiR technology is what we call our proprietary V rail technology within the Professional Fidelity series. The
Crossover uses this technology throughtout and makes it an outstandig device in terms of dynamic range, signal-
to-noise ratio and headroom. It delivers an exceptional sound experience with invincible serenity, transparency and
realness.
