I-HACK ATTACK™ BASEBALL PITCHING MACHINE
SPORTS ATTACK, LLC. • 800-717-4251 • sportsattack.com
6
Batting Practice
NOTE: As wheel speeds are
changed for different velocities
and spins, the ball will be pitched
to differing locations. Compen-
sate for these changes by turning
the elevation control, and by
moving the rear leg.
Figure 3 Present the ball to the hitter
Feeding the ball
IMPORTANT: Hitter should
stride the instant he sees the ball
release from the feeder’s hand at
the upper end of the ball chute.
PITCH LOCATORS
Pitch Locators Purpose
Pitchlocatorsadjusttolimitchangeinthemovementofthethrowingheaddeningthe
location of the pitch: inside/outside and high/low or locked for repeatability.
There are three pitch locators and an elevation handle. Two pitch locators, left pitch locator
(LPL)andrightpitchlocator(RPL)controltheamountofhorizontal(inside/outside)pitch
location.(SeeFigure6).
Pitch Locators Functions
Locators in raised positon
1.Tolocatepitchinsideandoutsideforchangeinthehittersstrikezone(SeeFigure7).
2.Allowforwiderpitchesforcatcher’sblockingdrills(SeeFigure7).
3.Toallowheadtobelockedinpositionforpitchlocationrepeatability.(SeeFigure7).
4.Toallowforballstobethrownacrosswidthofineldorouteldforaroundballs/y
balls(fungo)fordefenssivework(Seepicabove).
WARNING
HAZARD FROM
HIGH-SPEED
PROJECTILES
Being struck by a pitched ball
can cause serious injury or death.
Make sure that no one steps in
front of I-Hack Attack while it is
connected to electric power.
Clear all hitters away from home
plate, the batter’s box and the
backstop area before connecting
I-Hack Attack to electric power.
Left Pitch
Locator(LPL)
Lower Position (Fungo)
Right Pitch
Locator(RPL)
Left Pitch
Locator(LPL)
Right Pitch
Locator(RPL)
Raised Position
(Pitches)
Figure 6
Figure 7
