V - ELECTRICAL CONNECTIONS
2
Using the side handle 4 it is possible to loosen the
projector when it is locked in a certain position and thus
change its inclination. In the same way, the projector is
rotated with respect to its vertical axis by loosening the
wing nut 9. By turning knob 8, the lamp carriage is shifted
forward or backward to widen or narrow the beam of light
respectively.
For utmost projector performance, both the lens and the
reflector must be kept as clean as possible. To do so, after
disconnecting the projector from the mains, open it and
clean both the lens and reflector with a soft cloth
dampened with alcohol.
VI - FOCUS AND REGULATIONS
VIII - MAINTENANCE
The projector must be serviced at least once a year to
check the integrity of its electrical and mechanical parts.
VII - CLEANING
For safety reasons always disconnect the projector from
the mains before opening it to change the lamp.
Open the projector lamp holder tray by means of knob 5.
Insert the lamp into the socket taking care not to touch the
glass. Please note that it is not necessary to change the
position of the lamp carriage and as a consequence the
optical adjustment of the projector remains unchanged.
WARNING!
TO MOUNT A 1200 W LAMP (WITH A HIGHER CENTRE
OF LIGHT) IN LIEU OF A 1000 W LAMP, THE PAN
FITTED WITH THE LAMP HOLDER MUST BE SHIFTED
FROM THE HIGH POSITION TO THE LOW POSITION
(SEE DIAGRAM) AFTER ROTATING THE RETAINING
SPRING 6. RE-POSITION THE SPRING AT THE END
OF THE OPERATION. .
IV - CHANGING THE LAMP
Your projector has been designed for a maximum voltage
of 240 V.
The power cable complies with standards CEI 20-35.
However one must make sure that the ground is always
connected.
Sintesi Line
Mod.AR 05- Ar12 -AR 25
Mod.VA 05- Va12 - VA 25
