3
1
2
7
8
5
4
3
6
WARNING - Use the tools provided to fasten the nuts. Do not over tighten the nuts. Do not
use power driver, torque wrench, or drill.
TIP - Fastening the nal two frame sections often requires additional effort. Two people
may be required for assembly.
Connect and fasten one frame section at a time together with the large nuts and bolts.
Attach a center post to the middle of each leg section.
Then, in the order shown in the illustration, lift the frame and evenly put the legs into the leg hole on
the frame. We recommend that two people work together to complete this step. One person to hold
the frame up and horizontal, and the other person to put the legs into the leg hole.
Fasten each leg to the frame before going to the next leg.
