Section 3A: Antenna Installation 27
Antenna Installation
4. Insert the mini-coax connector into the GPS antenna
port on the base station.
5. Locate the GPS antenna indoors on a flat surface.
Note:
Do not completely remove the plastic cover. The top of the
cover (closest to the antenna) is fastened to the base station
and should not be removed.
WARNING
Do not force the connector into the GPS antenna port as
this can damage the connector.
WARNING
The external GPS antenna should not be used outdoors.
Tip:
You can use double-sided tape to secure the bottom of the
GPS antenna to its new location.
