SPARCIN 9 / SPARCIN 9C
4
2. INSTALLATION
SPARCIN 9 is ready for use after connection to electric power and compressed air or some
technical gas for plasma cutting.
SPARCIN 9C (with built-in compressor) is ready for use after connection to electric power.
Power supply:
3~50Hz, 400V
Fuse: 16A slow blow
Important!
If the machine is to be connected to a power generator it is absolutely vital that the machine be
fitted with generator filter. If the machine is not fitted with generator filter, serious damage to
the machine and costly repair can be the result. Such damage is NOT covered by the warranty.
The generator must supply minimum 15 kVA exclusively for the SPARCIN 9/9C.
Gas supply ( SPARCIN 9 only )
Air plasma cutting:
Connect the compressed air to the filter regulator and adjust to 3,5-4 bar.
Gas plasma cutting;
Connect the constant flow regulator of the gas cylinder to the filter regulator and
adjust to 3,5-4 bar.
The gas flow should be approx. 18 l/min.
IMPORTANT! The quantity of plasma generating air/gas flowing is decided by a gas
injector situated in the connection between the gas hose and the torch body, and this is
unique for SPARCIN 9. PLEASE NOTE, the torch for SPARCIN 9C has a unique gas
injector.
The use of incorrect hose assembly may result in damage to the torch body as well as the
power source.
