SPX FLOW W62 - Page 59

Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 59
W64R/W84R Tank Outlet Valve
Item # 1" & 1-1/2" 2" 2-1/2" 3" 4" Notes
Control Top
1 Actuator
* 2 Bearing
3 Adapter, W60 (Std.) 102407+ 102408+ 102409+ 102410+
3a W60 109294+ 109295+
W80 116926+ 116927+
3b Adapter, W80 106292+ 106293+ 106294+ 106295+ 2
3d Adapter, Wiping Stem Seal 117880+ 117881+ 117882+ 117883+ 1
* 4 O-ring EPDM E70210 E70210 E70210 E70210
FKM V70210 V70210 V70210 V70210
* 4a EPDM 116183+ 116183+ 116183+ 116183+
FKM 115626+ 115626+ 115626+ 115626+
5 Clamp Standard 119-33 119-34 119-51 119-87
High Pressure 119-272 119-273 3
* 6 O-ring, Body EPDM E70228 E70232 E70236 E70244
FKM V70228 V70232 V70236 V70244
7
Tef-Flow
TM
102413+ 102414+ 102415+ 102416+
Tri Ring
108132+ 107045+ 108134+ 108135+
Metal 106388+ 106389+ 106390+ 106391+
* 8 Seat Ring
Tef-Flow
TM
20-241 20-242 20-243 20-244
Tef-Flow
TM
P
115348+ 115349+ 115350+ 115351+
Tri Ring, EPDM 107695+ 107048+ 102488+ 107698+
Tri Ring, FKM 107986+ 107982+ 107974+ 107989+
10 High Pressure Backup Ring
12 Tank Flange 1/8" Thick 114825+ 114826+ 114827+ 114828+
1/4" Thick 114830+ 114831+ 114832+ 114833+
PL5027-CH6
107983+
114824+
114829+
BURT210
119-271
E70223
V70223
20-240
115347+
107692+
N/A
102406+
109293+
116925+
106291+
117879+
E70210
V70210
116183+
115626+
Part Description
102757+
N/A
N/A
N/A
119-30
1
Stem (less seat
ring)
Adapter, High
Pressure
Wiping Stem
Seal
Contact Factory
See actuator parts list
102412+
108131+
106387+
* Recommended Spare Parts
1. Wiping Stem Seal Adapter and Wiping Stem Seal options available for W60 Series valves only.
2. W80 Adapter allows for liquid or steam flu
sh of stem o-ring only.
3. High Pressure Body Clamp only required for valves equipped with High Pressure Adapter (item 3a).
