SPX Reformer - Removing the Springs

To Next Page

To Previous Page

Fixed Cube Nut

Spring Anchoring Bar

Removing the Springs

1. With 7/16" wrench, hold fixed cube nut in place.

3. Remove spring from spring anchoring bar.

5. Repeat steps 1 to 4 on remaining springs.

2. Using second 7/16" wrench on opposite side of spring

anchoring bar, loosen nylon locknut. This may require exerting

abitof torque.

NOTE: Discard used nylon locknuts. (New nylon locknuts are

provided with new springs.)

4. Pull spring out of the spring holder.

6. Remove spring sleeves from old springs and slide onto

newsprings, if applicable.

Required Tools

2x Open-End Wrenches

1/2" x 7/16" (13 mm x 11 mm)
