SPYKER 288 SUPER - Spreader Assembly (Steps 5-8); Attach Accuway Lever and Connect Rod

39 Screen
5
Exploded View Model 288 Super
H
H
o
o
p
p
p
p
e
e
r
r
&
&
F
F
r
r
a
a
m
m
e
e
A
A
s
s
s
s
e
e
m
m
b
b
l
l
y
y
Spreader Assembly
4
5. Attach Accuway
lever to left handle
with two bolts [41]
and nuts [5].
6. Connect lever rod
pivot bracket to
pivot lever with
clevis pin [56] and
hair pin [57].
7. Tighten all bolts.
8. Spreader assembly
complete.
