SRA 250 - PARTS LIST FOR WELDER DIAGRAM

6
PARTS LIST FOR WELDER DIAGRAM
#
PART DESCRIPTION
#
PART DESCRIPTION
#
PART DESCRIPTION
#
PART DESCRIPTION
1
Three position
switch
16
Torch Hose Fitting
31
Power cable
46
Tank
2
Safety cap
17
Fitting 1/8’’
32
Cover
47
Rod Ø 6mm
3
Filling Neck
18
Front panel
33
Rubber ring
48
Register 5k 110v
10k 220v
4
Power control knob
19
Power control 110v-
220v
34
Handle
49
4a. fuse
5
Minimum level
indicator light
20
Rear panel
35
Fuse holder plug
50
Power transformer
terminal
6
Maximum level
indicator light
21
Brass screw for check
valve
36
Nut 6MA
51
RFI suppression
filter
7
Booster
22
Cap & tee screw O-
ring
37
Washer 6 mm
8
Tee screw
23
Check valve
38
Insulator Ø 6mm
9
Booster holder with
1/8’’ fitting
24
Booster seal gasket
39
Power transformer
110v-220v
10
Torch
25
Check valve O-ring
40
Fitting 1/8’’ 90°
11
Tips
26
Level circuit board
41
Rilsan tube 4x6 mm
12
On indicator light
27
Rectifier diodes
42
Minimum level
sensor
13
Check valve cap
28
Aluminum base plate
43
Tank cover
14
Torch holder/stand
29
Fan motor 110v-220v
44
Maximum level
sensor
15
Torch hose
30
Fan
45
Tank O-ring
