Page 7
ASSEMBLY (CONTINUED)
HEATER ELEMENT INSTALLATION
First, Locate the following items
- 5500 Watt Incoloy 800 alloy halo heating element
- Blue silicone kettle inset gasket
- Brass locknut washer
- Knurled lock nut
Begin by installing the blue silicone kettle inset gasket on the elements male threads.
Next feed the electrical connection and PT 100 3.5mm connection through the 2” TC element connection
point through the inside of the kettle out.
5500 Watt Incoloy 800 Alloy Halo Heating Element
Blue Silicone Kettle Inset Gasket
To Next Page
