ASSEMBLY
POWER SPECIFICATIONS
1V eCONTROLLER CONNECTIONS
2V eCONTROLLER CONNECTIONS
- 208-240VAC 60 Hz operation only
- 30A maximum total connected load
- Dedicated GFCI protected circuit required
(1) L6 - 30R Element Output
(1) 3.5MM Thermoprobe Connection Interface
(1) L6 - 30P 208-240VAC
Main Power Input
(1) 110VAC Accessory Power Input
(1) 110VAC Accessory Power Input
(1) L6 - 30P 208-240VAC Main power input
(2) L6 - 30R Element Output
(2) 3.5MM Thermoprobe
Connection Interface
(2) 110VAC NEMA 5-15P Side Mounted Controller
Receptacles (3 Amps max per outlet)
(2) 110V NEMA 5-15P Side Mounted Controller
Receptacles (3 Amps max per outlet)
