0000-00
ENGINE GENERAL
4. INTAKE SYSTEM LAYOUT
Supplying Compressed Air with
Turbocharger's Operation
Intake Manifold
Intake outlet hose
Front air duct
Air cleaner
Terbocharger
intercooler
Turbo charger
Inter cooler
Air cleaner
To corresponding cylinders
From intercooler
Coolant
port
